| 顯示內容 | 產品圖 | 型號 | 尺寸 (寸) |
外形尺寸 (mm) |
視域尺寸 (mm) |
引腳 | 視角 | 接口 | IC Part No. | 亮度 (cd/m2) |
溫度 (°C) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 128×32 |  |
QT-2832TW09108P01 | 0.91 | 30.0×11.50×1.2 | 22.384×5.584 | 插接8pin | ALL | I2C | SSD1306 | 150 (Min) cd/m2 | -40~80℃ |
| 128×32 |  |
QT-2832HW09114P01 | 0.91 | 30.0×11.50×1.2 | 22.384×5.584 | 14pin | ALL | I2C | SSD1306 | 150 (Min) cd/m2 | -40~80℃ |
| 128×32 |  |
QT-2832TW08708P01 | 0.87 | 29.0×8.7×1.2 | 21.356×5.324 | 插接8pin | ALL | 4-wire SPI | SSD1316 | 350(Min) cd/m2 | -40~80℃ |
| 128×32 |  |
QT-2832HW08715P01 | 0.87 | 29.0×8.7×1.2 | 21.356×5.324 | 15pin | ALL | 4-wire SPI | SSD1316 | 120 (Min) cd/m2 | -40~80℃ |
| 128×32 |  |
QT-2832HW08714P01 | 0.87 | 29.0×8.7×1.2 | 21.356×5.324 | 14pin | ALL | IIC | SSD1316 | 120 (Min) cd/m2 | -40~80℃ |
| 96×32 |  |
QT-9632HW08614P01 | 0.86 | 29.1×9.2×1.2 | 21.1×6.06 | 14pin | ALL | I2C | SSD1316 | 120 (Min) cd/m2 | -40~80℃ |
| 96 × 39 |  |
QT-9639HW08328P01 | 0.83 | 23.80 × 16.20 × 1.30 | 23.80 × 16.20 × 1.30 | 28 | ALL | 8-bit 68XX/80XX Parallel, 4-wire SPI, I2C | SSD1306 | 100 (Min) cd/m2 | -40~85℃ |
| 80*128 |  |
QT-80128HW07813P01 | 0.78 | 25.275x28.5x1.227 | 9.68 (W) x 17.26 | 13pin | ALL | I2C/4-wire SPI | SH1107 | 350(Min) cd/m2 | -40~85℃ |
| 128×88 |  |
QT-2888HW07312P01 | 0.73 | 14.6×22.34 | 10.54×15.34 | 12pin | ALL | I2C/4-wire SPI | SH1107 | 70 (Min) cd/m2 | -40~85℃ |
| 48×64 |  |
QT-4864HW07114P02 | 0.71 | 13.9×22×1.2 | 10.54×14.7 | 長排線14 | ALL | 4-wire SPI | SSD1306 | 100 (Min) cd/m2 | -40~80℃ |
| 48×64 |  |
QT-4864HW07114P01 | 0.71 | 13.9×22×1.2 | 10.54×14.7 | 15/14 | ALL | 4-wire SPI | SSD1306 | 100 (Min) cd/m2 | -40~80℃ |
| 96×16 |  |
QT-9616HW06908P02 | 0.69 | 26.3×8×1.2 | 17.26×3.18 | 8pin | ALL | I2C | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
 |
