| 顯示內容 | 產品圖 | 型號 | 尺寸 (寸) |
外形尺寸 (mm) |
視域尺寸 (mm) |
引腳 | 視角 | 接口 | IC Part No. | 亮度 (cd/m2) |
溫度 (°C) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 96×16 |  |
QT-9616HW06914P01 | 0.69 | 26.3×8×1.2 | 17.26×3.18 | 14pin | ALL | I2C | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
| 96×16 |  |
QT-9616HW06914P03 | 0.69 | 24 × 6.9 × 1.25 | 17.26 ×3.18 | 14pin | ALL | I2C | SSD1312 | 120 (Min) cd/m2 | -40~80℃ |
| 96*32 |  |
QT-9632HW06825P01 | 0.68 | 19.7 x 12.7 x1.22 | 16.3 x5.42 | 25pin | ALL | Parallel /I2C/ 4-wire SPI | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
| 64×48 |  |
QT-6448HW06628P02 | 0.66 | 16.42 x16.9 x 1.25 | 13.42×10.06 | 28 | ALL | Parallel /I2C/ 4-wire SPI | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
| 64×48 |  |
QT-6448HW06628P01 | 0.66 | 18.46×18.1×1.5 | 13.42×10.06 | 28 | ALL VIEW | Parallel /I2C/ 4-wire SPI | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
| 120*28 |  |
QT-2028HW06314P01 | 0.63 | 21.54 x 6.62 x 1.22 | 15.58 x3.62 | 焊接14pin | ALL VIEW | IIC | SSD1312 | 120(Min)CD | -65~150 |
| 96*32 |  |
QT-9632HW05414P01 | 0.54 | 18.52 x 7.04 x 1.22 | 12.46 x4.14 | 焊接14pin | ALL VIEW | IIC | CH1115 | 240(Min) cd/m2 | -40~80℃ |
| 48*88 |  |
QT-8848HW0514P01 | 0.5 | 8.928*14.05*1.02 | 6.124*11.244 | 焊接14pin | All Viewing direction | IIC | CH1115 | 470 (Min) cd/m2 | -40~80℃ |
| 48*88 |  |
QT-4888CW0517P01 | 0.5 | 8.928*14.05*1.02 | 6.124*11.244 | 插接17pin | All Viewing direction | IIC | CH1115 | 470(Min) cd/m2 | -40~80℃ |
| 64×32 |  |
QT-6432HW04914P02 | 0.49 | 14.5×11.6×1.2 | 11.18×5.58 | 長排14 | All Viewing direction | I2C | SSD1306 | 180 (Min) cd/m2 | -40~80℃ |
| 64×32 |  |
QT-6432HW04914P01 | 0.49 | 14.5×11.6×1.2 | 11.18×5.58 | 14pin | All Viewing direction | I2C | SSD1306 | 180 (Min) cd/m2 | -40~80℃ |
| 72×40 |  |
QT-7240HW04216P01 | 0.42 | 12.0×11.0×1.2 | 9.196×5.18 | 16pin | All Viewing direction | 4-wire SPI/I2C | SSD1306 | 120 (Min) cd/m2 | -40~80℃ |
 |
